S2700-9TP-EI-DC Specification | |
Downlink ports | 8 × 10/100Base-TX Ethernet ports |
Uplink ports | 1 dual-purpose 10/100/1000 or SFP |
MAC address | 8K MAC address entries |
VLAN feature | 4K VLANs, complying with IEEE 802.1Q |
MAC address-based assignment | |
QoS | Port-based rate limiting and flow-based rate limiting |
N/A | |
IPv6 feature | IPv6 protocol |
Multicast | MVLAN |
Reliability | STP (IEEE 802.1d), RSTP (IEEE 802.1w), MSTP (IEEE 802.1s), and RRPP topology and RRPP multi-instance |
Traffic sampling | N/A |
Security & access features | 802.1x authentication and limit on the number of users on an interface |
Multiple authentication methods including AAA authentication, RADIUS authentication, and TACACS+ authentication | |
Surge protection | Surge protection capability of service ports: 6 kV (The surge protection capability of service ports on PoE switches is 1 kV.) |
Management | Stack (S2710-52P-SI-AC, S2710-52P-PWR-SI, S2700-52P-EI-AC, S2700-52P-PWR-EI) |
Operating environment | Long-term operating temperature: –5°C to + 50°C |
Power | DC: |
Dimensions (W x D x H) | 250 × 180 × 43.6 mm |
Weight | S2700-9TP-EI<1.4 kg |
Power consumption | S2700-9TP-EI<12.8 W |
