Huawei S5700 Series Switches S5720S-28P-PWR-LI-AC|LinkNewNet

Huawei S5700 Series Switches S5720-52P-LI

Model: S5720-52P-LI

Detail: Huawei S5700 Series Switches 48 Ethernet 10/100/1000 ports, 4 Gig SFP, AC power support, Overseas

Condition: USED

List Price: $876 Price: $526

Price is not finalPlease contact if any inquiry.

Shipping: DHL, FedEx, UPS, etc

Availability: In Stock

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Product Details

S5720-52P-LI
Product list
Product code	S5720-52P-LI
Memory (RAM)	512 MB
Button	512 MB in total. To view the available flash memory size, run the display version command.
Product parameters
Network Ports	52
Mean time between failures (MTBF)	41 years
Mean time to repair (MTTR)	2 hours
Availability	> 0.99999
Service port surge protection	Common mode: ±7 kV
Power supply surge protection	±6 kV in differential mode, ±6 kV in common mode
Stack ports	Forty-eight 10/100/1000BASE-T ports and four 1000BASE-X ports
Expansion Slot Type	SFP
Certification	EMC certification Safety certification Manufacturing certification
Stack ports	Forty-eight 10/100/1000BASE-T ports and four 1000BASE-X ports
Memory
Memory Technology	DRAM
Standard Memory	512 MB
Flash Memory	128 MB
Power Device
Rated voltage range	100 V AC to 240 V AC, 50/60 Hz
Maximum voltage range	90 V AC to 264 V AC, 47 Hz to 63 Hz
Physical specifications
Width	17.4 in
Height	1.72 in
Depth	9.21 in
Weight	10 lbs
Environmental Parameters
Min Temperature	23 °F
Max Temperature	131 °F
Humidity Operating	5 - 95% (non-condensing)

Q&A

Q Do you have any recommended models for S5720-52P-LI?

A Yes, of course. OMXD30000, SFP-GE-LX-SM1310, OMXD30009, ESFP-GE-SX-MM850 for optical transceiver module.

Q What's the dimensions (W x D x H) of S5720-52P-LI?

A 17.4in × 9.21in × 1.72in.

Q What are the common causes for SSH Login Failure on S series switches?

A The configuration is incorrect. For example, the STelnet service is disabled on the switch.
Solution: Check whether the configuration is correct and complete by referring to "Example for Configuring STelnet Login."

Q What is the Huawei S5700 series switch?

A S5700 series Ethernet switches are next-generation energy-saving GE switches designed to provide high-bandwidth access and Ethernet multi-service aggregation. Based on cutting-edge hardware and Huawei Versatile Routing Platform (VRP) software, the S5700 provides a large switching capacity, high reliability (double power slots and hardware Ethernet OAM), and high-density GE ports to accommodate 10 Gbit/s upstream transmissions. It also supports Energy Efficient Ethernet (EEE) and iStack. The S5700 can be used in extensive enterprise network scenarios. For example, it can function as an access or aggregation switch on a campus network, a gigabit access switch in an Internet data center (IDC), or a desktop switch to provide 1000 Mbit/s access for terminals.
