Cisco Catalyst 3850 Series Switch WS-C3850-24S-S

Model: WS-C3850-24S-S

Detail: Catalyst 3650 Switch24 Port PoE 2x10G Uplink LAN Base

Condition: Used

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

WS-C3850-24S-S
Product list
Product code	WS-C3850-24S-S
Enclosure Type	1RU
Feature Set	IP Base
Product parameters
Network Ports	24
RJ-45 Ports	24
Available POE Power	None
Stack bandwidth	160 Gpbs
Switching Capacity	88 Gbps
Forwarding Performance	68.45Mpps
Introduction	The Cisco Catalyst 3650 Series Switch, with Cisco StackWise-160 Technology, can stack 9 switches and support up to 160 Gpbs stack bandwidth. The WS-C3650-24PD-L integrates with 24 POE+ Ethernet ports and 2 x 10G SFP+ or 4 x 1G SFP uplink ports in LAN base feature set.
Memory
RAM	4 GB
Flash Memory	2 GB
Physical specifications
Width	17.5 in
Height	1.75 in
Depth	17.7 in
Package Weight	13.5 pounds
Environmental Parameters
Min Temperature	23 °F
Max Temperature	113 °F
Humidity Operating	10 - 90% (non-condensing)

Q&A

Q What are the supported uplink modules in the Cisco Catalyst 3850?

A The Cisco Catalyst 3850 supports the following uplink modules:
● 4 x 1GE network module
● 2 x 1/10GE network module
● 4 x 1/10GE network module (can be used for the 48-port RJ-45 models and for the 12-port (or higher) 10‑gigabit-capable models)
● 8 x 10GE network module (can be used on the 24-port and 48-port multigigabit switch and also on the 24‑port 10G SFP+ switch)
● 2 x 40GE network module (can be used on the 24-port and 48-port multigigabit switch and also on the 24‑port 10G SFP+ switch)

Q What are the different types of licenses in the Cisco Catalyst 3850?

A There are two main types of Cisco Catalyst 3850 license: permanent RTU license and evaluation RTU license. These are available for both image-based licensing (IP Base or IP Services) and AP count licensing. A permanent RTU license is a paid license, with no expiration date. The universal Cisco IOS XE Softwarebased images have all three license levels: LAN Base, IP Base, and IP Services. RTU CLI commands enable the switch license to be moved between different license levels. An evaluation RTU license allows the customers to evaluate image-based and/or AP count license for 90 days at no cost.

Q What management ports are available on the Cisco WS-C3850-24S-S?

A The Cisco Catalyst 3850 comes with a 10/100 Ethernet dedicated management port on the backside of the switch right above the console port. This port is in separate VRF called “Mgmt-vrf.” This is to segment the management traffic from the global routing table of the switch.
