| CISCO7201 | |
| Product list | |
| Product code | CISCO7201 |
| Description | Cisco 7201 Chassis, 1GB Memory, Dual P/S, 256MB Flash |
| Processor | 1.67-GHz Motorola Freescale 7448 processor |
| Performance | 2,000,000 pps or more |
| Product parameters | |
| Memory | |
| Gigabit Ethernet Optics | SFP • Short wave (SX) • Long wave/long haul (LX/LH) • Extended wavelength (ZX) • RJ-45 copper SFP |
| Services Performance Engine module | w/SPE 250 |
| Rack Units | 3U |
| Interfaces | 4 integrated 10/100/1000 Ethernet ports with 2 SFP ports |
| Expansion Slot(s) | 4 service module slots 3 Enhanced High-Speed WAN Interface Card slots 3 onboard digital signal processor (DSP) slots |
| DRAM Memory | 1 GB default (2 GB maximum) |
| Flash Memory | 64 MB default (256 MB maximum) |
| Power Device | |
| Physical specifications | |
| Width | 16.9 in |
| Height | 1.75in |
| Depth | 19in |
| Weight | 16.5 lb |
| Environmental Parameters | |
| Min Temperature | 32 °F |
| Max Temperature | 104 °F |
| Humidity Operating | 10- 85% (non-condensing) |
