7206VXR/NPE-G1 Specification | |
Product Number | 7206VXR/NPE-G1 |
Product Description | Cisco 7206VXR with NPE-G1 includes 3GigE/FE/E Ports and IP SW |
Manufacturer | Cisco Systems, Inc |
Product Type | Router |
Form Factor | Rack-mountable - modular - 3U |
Dimensions (WxDxH) | 42.7 cm x 43.2 cm x 13.3 cm |
Processor | 1 x Broadcom BCM1250 700 MHz |
DRAM Memory | 256 MB (installed) / 1 GB (max) - DDR SDRAM |
Flash Memory | 64 MB (installed) / 256 MB (max) |
Routing Protocol | OSPF, IGRP, RIP, IS-IS, BGP, EIGRP, HSRP |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Network / Transport Protocol | TCP/IP, UDP/IP |
Remote Management Protocol | SNMP, Telnet |
Features | Cisco IOS IP Plus , modular design, full duplex capability, DHCP support, NAT support, RARP support, ARP support, VLAN support |
Compliant Standards | IEEE 802.1Q |
Power | AC 120/230 V AC 100/240 V ( 50/60 Hz ) |
Data Transfer Rate | 1 Gbps |
Bundled with | Cisco 7200VXR NPE-G1 Network Processing Engine |
