CISCO7201 Specification | |
Product Number | CISCO7201 |
Description | Cisco 7201 Chassis, 1GB Memory, Dual P/S, 256MB Flash |
Processor | 1.67-GHz Motorola Freescale 7448 processor |
LAN ports | 4 Gigabit Ethernet ports |
Gigabit Ethernet Optics | SFP • Short wave (SX) • Long wave/long haul (LX/LH) • Extended wavelength (ZX) • RJ-45 copper SFP |
DRAM | 1 GB default (2 GB maximum) |
Compact Flash | 64 MB default (256 MB maximum) |
Cisco IOS Software Release | 12.2(31)SB4, 12.4XD7, and 12.4PI6 |
Dimensions (H x W x D) | 1.75 x 19 x 16.9 in. (4.44 x 48.26 x 42.93 cm) |
Weight | Chassis fully configured with a port adapter ~16.5 lb (7.48 kg) |
Heat Dissipation | 290 Btu/hr at 85W typical input power 512 Btu/hr at 150W maximum input power |
Operating Temperature | 32 to 104ºF (0 to 40ºC) |
Storage Temperature | -4 to 149ºF (-20 to 65ºC) |
Operating Humidity | 10 to 90% non-condensing |
Storage Relative Humidity | 5 to 95% |
Operating Altitude | 60 to 2000m |
Performance | 2,000,000 pps or more |
