Cisco Catalyst 3750-G Series Switch WS-C3750G-24TS-S|LinkNewNet

Cisco Catalyst 3750-G Series SwitchWS-C3750G-24TS-S

Model: WS-C3750G-24TS-S

Detail: Cisco Catalyst 3750 Series Switches (Figures 1 through 4) are innovative switches that improve LAN operating efficiency by combining industry-leading ease of use and high resiliency for stackable switches.

Condition: Used

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Tags： 24 port

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

WS-C3750G-24TS-S
Product list
Product code	WS-C3750G-24TS-S
Power cable	No
Button	No
Product parameters
Network Ports	24
Product Description	Catalyst 3750X 24 Port GE SFP IP Services
Form Factor	Fixed, Rack Mountable 1U, Stackable/Clustering
Switch Port density - Uplinks	12 x Gigabit SFP
Performance	Switching capacity : 32 Gbps Forwarding performance : 17.8 Mpps
Stack Port	Yes
Number of Total Expansion Slots	9
Routing Protocol	RIP-1, RIP-2, HSRP, static IP routing, RIPng
Features	Flow control, full duplex capability, Layer 3 switching, auto-sensing per device, IP-routing, DHCP support, auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, stackable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, Jumbo Frames support, Cisco StackWise Technology, Cisco EnergyWise technology, Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN)
Introduction	Cisco Catalyst 3750 Series Switches (Figures 1 through 4) are innovative switches that improve LAN operating efficiency by combining industry-leading ease of use and high resiliency for stackable switches.
Memory
Standard Memory	128 MB
Memory Technology	DRAM
Flash Memory	16 MB
Power Device
PoE Port	No
Input Voltage	110 V AC
Physical specifications
Width	44.5 cm
Height	4.4 cm
Depth	32.6 cm
Weight	4.6 kg
Environmental Parameters
Min Temperature	23 °F
Max Temperature	131 °F
Humidity Operating	5 - 95% (non-condensing)

Q&A

Q What is the difference between Cisco 3750 and 3560?

A 3560's and 3750 are eventually the same switches. The only difference is that 3750's switches are based on stacking capabilties. They have a High-Speed stacking bus to give stacking capabilties.

Q What is the speed of a 3750G port?

A The 3750G series of switches builds upon the already powerful 3750 product line, upgrading the main port speed from 10/100 Fast Ethernet to 10/100/1000 Gigabit speeds.

Q What is Cisco 3750g?

A The Cisco WS-C3750G-24TS-S is a powerful and feature-rich switch designed for small to medium-sized businesses and enterprise networks. This switch provides advanced functionality, high-performance, and reliable network connectivity to support critical business applications and services.

Q What is the difference between Cisco PoE and PoE+?

A The big difference between 802.3af (PoE) and 802.3at (PoE+) is the amount of power delivered over each standard. 802.3af (PoE) can deliver 15.4 watts over Cat5 cables. 802.3at (PoE+) can deliver up to 30 watts over Cat 5 cables with 25.5 watts available to devices.
