Cisco Catalyst 2950 Series Switch WS-C2950-24|LinkNewNet

Cisco Catalyst 2950 Series Switch WS-C2950-24

Model: WS-C2950-24

Detail: 10/100 Catalyst Switch 24 port Standard Image only

Condition: Used

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Tags： 24 port

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

WS-C2950-24
Product list
Product code	WS-C2950-24
Power cable	No
Button	No
Product parameters
Port	24
Port Details	24 x Fast Ethernet Network
Ethernet Technology	Fast Ethernet
Network Technology	10Base-T 100Base-TX
Manageable	Yes
Standard Memory	16 GB
Flash Memory	8 GB
Standards	IEEE 802.1x support (planned future software support) IEEE 802.3x full duplex on 10BaseT, 100BaseTX, and 1000BaseT ports IEEE 802.1D Spanning-Tree Protocol IEEE 802.1p CoS IEEE 802.1Q VLAN IEEE 802.3ab 1000BaseT specification IEEE 802.3u 100BaseTX specification IEEE 802.3 10BaseT specification
Introduction	The Cisco Catalyst 2950-24 is a member of the Cisco Catalyst 2950 Series switches, and is a standalone, fixed-configuration, managed 10/100 switch providing user connectivity for small to mid-sized networks.
Power Device
Power Source	Power Supply
Power Consumption	30W
Input Voltage	110 V AC 220 V AC
Physical specifications
Width	17.5 in
Height	1.7 in
Depth	9.5 in
Weight	6.5 lbs
Environmental Parameters
Min Temperature	23 °F
Max Temperature	113 °F
Humidity Operating	10 - 90% (non-condensing)

Q&A

Q What does the system LED is amber on a new Catalyst 2950 series switch What does this indicate?

A The switch automatically runs POST which is a series of self-tests to verify proper functioning, after the power is connected.

Q How to reset Catalyst 2950 switch?

A Step 1: turn off/on the switch while holding the button down for roughly 15 seconds.

Step 2: You will be able to view the led lights blink, and now the switch should have reset to default on system restart once you release the mode button. When you're unable to log in, you must complete a password rescue.

Q How to configure a Cisco Catalyst 2950?

A Connect the serial cable that came with the switch to the console port on the switch and to a serial port on your computer. The cable that comes with the switch is typically blue, and the serial end is a 9-pin d-shell connector.
