Huawei S1700 Series Switches S1700-16G|LinkNewNet

Huawei S1700 Series Switches S1700-16G

Model: S1700-16G

Detail: Huawei S1700-16G(16 Ethernet 10/100/1000 ports,AC 110/220V)

Condition: Used

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

S1700-16G Specifications
Type	Huawei S1700 Unmanaged Switch
Downlink Ports	16 Ethernet 10/100/1,000 ports
Uplink Ports	Shared with downlink ports
MAC Address Table	8K MAC
Forwarding Performance	24 Mpps
Switching Capacity	32 Gbit/s
Dimensions in mm (W x D x H)	320 x 208 x 43.6
Input Voltage	Rated AC power: 100V to 240V; 50 Hz/60 Hz Maximum AC voltage: 90V to 264V; 47 Hz/63 Hz
EEE	NA
Power Consumption	< 10W
Heat Dissipation	Fan-free natural heat dissipation

Q&A

Q What is the difference between Cisco and Huawei?

A Huawei uses only open standard protocols whereas Cisco uses a mixture of open and proprietary.

Q What is a Huawei switch?

A Using intelligent, multi-layer switching technology, Huawei's Ethernet switches provide High-Definition (HD) video stream transmission, elastic cloud computing, IPv6-capable hardware, integrated security protection, and Hierarchical Quality of Service (HQoS)-based refined services.

Q How do I connect my Huawei switch to my computer?

A Connect the DB9 female connector of the console cable to the serial port (COM) on the PC, and connect the RJ45 connector to the console port on the switch. Configure terminal emulation software and log in to the Switch. Configure basic information for the Switch.
