| CTS-C60CODEC-K9 | |
| Product list | |
| Product code | CTS-C60CODEC-K9 |
| Product Type | Video conferencing device |
| Product parameters | |
| Digital Signaling Protocol | H.323, SIP |
| Data Compression Protocol | H.264 |
| Supported Display Graphics | VGA (640x480), XGA (1024x768), SVGA (800x600), SXGA (1280x1024), UXGA (1600x1200), HDTV (1920x1080), WUXGA (1920 x 1200), HD (1280 x 720), 1360x768, 1280x768, 1366x768 |
| Digital Video Standard | Digital Visual Interface (DVI), High-Definition Multimedia Interface (HDMI) |
| Network/Transport Protocol | TCP/IP |
| Voice output | Codec board |
| Network Protocols | Network Protocols |
| Compliant Standards | EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class B, FCC Part 15 B, UL 60950-1, EN 60950-1, CSA C22.2 No. 60950-1-07 |
| Power Device | Power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Physical specifications | |
| Width | 17.4 in |
| Depth | 10.9 in |
| Height | 1.7 in |
| Weight | 8.82 lbs |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 90% |
