C1-N5596T-FA | |
Product list | |
Product code | N3K-C3048TP-1GE |
Device Type | Switch - 48 ports - managed |
Enclosure Type | Rack-mountable 2U |
Product parameters | |
Port | 32 |
Port Type | 32 x 10GBase-T + 16 x SFP+ |
Subtype | 10 Gigabit Ethernet |
Remote Management Proto | SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH-2, CLI |
Encryption Algorithm | AES |
Authentication Method | RADIUS, TACACS+, MS-CHAP |
Layer Supported | 2 |
Features | Layer 2 switching, ARP support, VLAN support, Syslog support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) support, Multiple Spanning Tree Protocol (MSTP) support, Data Center Bridging Exchange (DCBX) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, front to back airflow, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Link Aggregation Control Protocol (LACP), 4 fans |
Introduction | Gain flexible and scalable deployment options for your server access fabric. The Cisco Nexus 5596T Switch is based on the 10GBASE-T standard (IEEE 802.3an) and Cisco NX-OS software, providing easy management and outstanding reliability. |
Power Device | |
Power Device | Internal power supply - hot-plug |
Installed Qty | 2 (installed) / 2 (max) |
Power Provided | 1100W |
Voltage Required | AC 120/230 V (50/60 Hz) |
Physical specifications | |
Width | 17.3 in |
Height | 3.5 in |
Depth | 29.5 in |
Weight | 47.5 lbs |
Environmental Parameters | |
Min Temperature | 32 °F |
Max Temperature | 104 °F |
Humidity Operating | 10 - 85% (non-condensing) |
