Cisco Nexus 3000 Series Switch N3K-C3172PQ-XL

Model: N3K-C3172PQ-XL

Detail: Nexus 3172PQ-XL Chassis, 48 SFP+ and 6 QSFP+ ports

Condition: Used

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

N3K-C3172PQ-XL
Product list
Product code	N3K-C3172PQ-XL
Power cable	No
Button	No
Product parameters
SFP+ Ports	48
QSFP+ Ports	6
Layer Supported	3
Management	POAP Python scripting Cisco EEM Switch management using 10/100/1000-Mbps management or console ports CLI-based console to provide detailed out-of-band management In-band switch management Locator and beacon LEDs Configuration rollback SSHv2 Secure Copy (SCP) server Telnet AAA AAA with RBAC RADIUS TACACS+ Syslog Syslog generation on system resources (for example, FIB tables) Embedded packet analyzer SNMP v1, v2, and v3 Enhanced SNMP MIB support XML (NETCONF) support Remote monitoring (RMON) Advanced Encryption Standard (AES) for management traffic Unified username and passwords across CLI and SNMP Microsoft Challenge Handshake Authentication Protocol (MS-CHAP) Digital certificates for management between switch and RADIUS server Cisco Discovery Protocol Versions 1 and 2 RBAC SPAN on physical layer, port channel, and VLAN Tunable buffer allocation for SPAN Encapsulated Remote SPAN (ERSPAN) Ingress and egress packet counters per interface PTP (IEEE 1588) boundary clock Network Time Protocol (NTP) Cisco OHMS Comprehensive bootup diagnostic tests Cisco Call Home Cisco DCNM Advanced buffer utilization monitoring sFlow
Introduction	N3K-C3172PQ-XL Equipped with 48 SFP+ and 6 QSFP+ ports, a new or pre-owned N3K-C3172PQ-XL is a highly programmable switch suited for 1/10/40-Gbps densities at line rate speeds. Designed to increase network visibility and improve monitoring while simplifying management, a new surplus or used N3K-C3172PQ-XL from Cisco is perfect for general-purpose deployments, high-frequency trading (HFT), high-performance computing (HPC), massively scalable data center (MSDC), as well as cloud networks. In addition a new or refurbished N3K-C3172PQ-XL fixed switch is also compact.
Physical specifications
Width	17.3 in
Height	1.7 in
Depth	17 in
Weight	18.6 lbs
Environmental Parameters
Min Temperature	23 °F
Max Temperature	131 °F
Humidity Operating	5 - 95% (non-condensing)

Q&A

Q What is the difference between Nexus 2000 and 3000?

A Both of them are designed for data centers but there are some differences.

Q What's the configuration for the Cisco Nexus 3172PQ and 3172PQ-XL?

A 48 fixed 10 Gigabit Ethernet SFP+ ports (can operate at 100-Mbps, 1-Gbps, and 10-Gbps speeds) and 6 fixed QSFP+ ports (each QSFP+ port can support 4 x 10 Gigabit Ethernet or 40 Gigabit Ethernet)

Q What is the Cisco Nexus 3000 Series Switches？

A The Cisco Nexus®3000 Series Switches are a comprehensive portfolio of 1, 10, and 40 Gigabit Ethernet switches built from a switch-on-a-chip (SoC) architecture. Introduced in April 2011, this series of switches provides line-rate Layer 2 and 3 performance and is suitable for top-of-the-rack (ToR) architecture. This series of switches has established itself as a leader in high-frequency trading (HFT), high-perance coformmputing (HPC), and big data environments by pairing high performance and low latency with innovations in performance visibility, automation, and time synchronization.
