Cisco Catalyst 3850 Series Switch WS-C3850-12S-E

Model: WS-C3850-12S-E

Detail: Cisco Catalyst 3850 Series Switch WS-C3850-12S-E Layer 3 Switch 12 Port GE SFP IP Base

Condition: Used

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Tags：

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

WS-C3850-12S-E
Product list
Product code	WS-C3850-12S-E
Power cable	No
Button	No
Product parameters
Port	12
Port Type	SFP Network Interface Module (NIM)
Ethernet Technology	10 Gigabit Ethernet
Network Technology	1000Base-X
Layer Supported	3
Standard Memory	4 GB
Flash Memory	2 GB
Management	Web Based Management Telnet CLI DHCP QoS VLAN RMON I and II standards SNMP v1, v2c, and v3 Syslog MIB
Compliant Standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Introduction	WS-C3850-12S-S is the next generation of enterprise-class stackable Ethernet access and aggregation layer switches that provide full convergence between wired and wireless on a single platform. WS-C3850-12S-S support full IEEE 802.3at Power over Ethernet Plus (PoE+), Cisco Universal Power over Ethernet (Cisco UPOE), modular and field-replaceable network modules, RJ45 and fiber-based downlink interfaces, and redundant fans and power supplies.
Power Device
Power Source	Power Supply
Max Supported Qty	2
Input Voltage	120 V AC 230 V AC
Physical specifications
Width	17.5 in
Height	1.8 in
Depth	17.7 in
Weight	15.48 lbs
Environmental Parameters
Min Temperature	23 °F
Max Temperature	113 °F
Humidity Operating	10 - 90% (non-condensing)

Q&A

Q Does the Cisco Catalyst 3850 support 802.1ae on downlink ports?

A The Cisco Catalyst 3850 is hardware capable for 802.1ae on all ports on the switch. Software support will be available later.

Q How do you manage the Cisco Catalyst 3850?

A The Cisco Catalyst 3850 can be managed using the Cisco IOS Software CLI or using Cisco Prime ™ Infrastructure 2.0.

Q Does the Cisco Catalyst 3850 10G SFP+ 48-port switch support uplink modules?

A No. It has 4 fixed 40G QSFP ports for uplinks. This is not field-replaceable.

Q What are the supported uplink modules in the Cisco Catalyst 3850?

A The Cisco Catalyst 3850 supports the following uplink modules:

● 4 x 1GE network module

● 2 x 1/10GE network module

● 4 x 1/10GE network module (can be used for the 48-port RJ-45 models and for the 12-port (or higher) 10‑gigabit-capable models)

● 8 x 10GE network module (can be used on the 24-port and 48-port multigigabit switch and also on the 24‑port 10G SFP+ switch)

● 2 x 40GE network module (can be used on the 24-port and 48-port multigigabit switch and also on the 24‑port 10G SFP+ switch)
