ASR1001-5G-VPNK9 Specification | |
General | |
Device Type | Router - with Cisco ASR 1000 Series Embedded Services Processor, 5Gbps |
Enclosure Type | Desktop, rack-mountable |
Connectivity Technology | Wired |
Performance | Bandwidth: 2.5 Gbps ¦ VPN throughput (IPSec): 1.8 Gbps |
Features | Firewall protection, NAT support, VPN support, Intrusion Prevention System (IPS), Access Control List (ACL) support, Quality of Service (QoS) |
Compliant Standards | CISPR 24, EN55022, VCCI Class A ITE, EN55024, CISPR 22, EN50082-1, CSA 22.2 No. 60950, EN 61000-6-1, AS/NZS 60950-1, AS/NZ 3548 Class A, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1 |
Processor | Core Duo |
RAM | 4 GB (installed) / 8 GB (max) |
Expansion / Connectivity | |
Interfaces | Management: 1 x 10Base-T/100Base-TX - RJ-45 ¦ Management: 1 x console - RJ-45 ¦ Management: 1 x auxiliary - RJ-45 ¦ USB: 1 x ¦ 4 x SFP (mini-GBIC) |
Expansion Slots | 1 (total) / 0 (free) x expansion slot |
Power | |
Power Device | Internal power supply |
Power Redundancy | Yes |
Installed Qty | 2 (installed) / 2 (max) |
Voltage Required | AC 120/230 V (50/60 Hz) |
Software / System Requirements | |
OS Provided | Cisco IOS Advanced Enterprise Services |
Dimensions & Weight | |
Width | 17.3 in |
Depth | 18.5 in |
Height | 1.7 in |
Environmental Parameters | |
Min Operating Temperature | 41 °F |
Max Operating Temperature | 104 °F |
Humidity Range Operating | 10 - 85% |
