HWIC-1GE-SFP Specifications | |
General Information | |
Manufacturer: | Cisco |
Product ID: | HWIC-1GE-SFP |
Product Description: | Cisco GigE High Speed WIC With One SFP Slot |
Product Type: | HWIC |
Technical Information | Wide Area Network |
Media & Performance | |
Data Transfer Rate: | 1 Gbps Gigabit Ethernet |
I/O Expansions | |
Expansion Slots: | 1 x SFP (mini-GBIC) |
Daughter Cards: | No |
Management & Protocols | |
Management: | · CiscoWorks · Simple Network Management Protocol (SNMP) support · Remote Monitoring (RMON) support · Cisco NetFlow accounting · VLAN |
Protocols: | VRRP, HSRP, RMON, SNMP, MPLS, IPSec, IGMP, CGMP, GLBP |
Security Features: | IPSec |
Environmental Conditions | |
Temperature: | 32°F (0°C) to 104°F (40°C) Operating -4°F (-20°C) to 149°F (65°C) Storage |
Humidity: | 10% to 90% Non-condensing Relative Humidity |
Physical Characteristics | |
Dimensions: | 0.8" Height x 3.1" Width x 4.8" Depth |
Miscellaneous | |
Additional Information: | · Jumbo frame support up to 9576 bytes · Hot insertion and removal for SFPs on all platforms · Media or SFP type display through a command-line interface (CLI) · Gigabit EtherChannel for link redundancy · Layer 3 VPN support |
System Requirements: | Minimum IOS Software Requirement: Cisco IOS Software Release 12.3(8)T4 |
Certifications & Standards: | · IEEE 802.3 with 802.2 SAP · IEEE 802.3 with 802.2 and SNAP · IEEE 802.1p · IEEE 802.1q VLAN · Gigabit Ethernet IEEE 802.3z, IEEE 802.3x, IEEE 802.3ab Agency Approvals: · UL 1950 (United States) · CSA-C22.2 #950 (Canada) · EN60950 (Europe) · TUV GS (Germany) · IEC 950 (International) Immunity: · EN300386 · EN55024/CISPR24 · EN50082-1 Emissions: · FCC Part 15 Class A · ICES-003 Class A · EN55022 Class A · CISPR22 Class A · AS/NZS 3548 Class A · VCCI Class A · EN 300386 · EN61000-3-3 · EN61000-3-2 |
