ASR-9006-DC-V2 - Cisco Router ASR 9006

Model: ASR-9006-DC-V2

Detail: Cisco ASR 9006 System ASR-9006-DC-V2 ASR 9006 DC Chassis with PEM Version 2

Condition: Used

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Tags：

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

ASR-9006-DC-V2 Specifications
Description	Cisco ASR 9006 System ASR-9006-DC-V2 ASR 9006 DC Chassis with PEM Version 2
Cisco ASR 9006 Specs
Physical specifications	Height: 17.50 in. (444.5 mm) (10 RU) Width: 17.38 in. (441.45 mm) Depth: ● With doors: 29.05 in. (737.9 mm) ● Without doors: 29.05 in. (737.9 mm) Weight: ● 89.55 lb (40.7 kg) (chassis with PEM) 150 lb (65.91 kg) (fully loaded, excluding line cards and power modules) – RSP, two v2 FAN trays, PEMs
Slot orientation	Horizontal
Cisco ASR 9000 Series RSP	Dual redundant RSPs with integrated fabric in 2 slots
Cisco ASR 9000 Series line cards	4 line-card slots
“Commons” components	2 RSPs 2 fan trays 1 PEM (either DC or AC) 1 fan filter
Reliability and availability	Fabric redundancy Fan redundancy Feed redundancy Power-supply redundancy RSP redundancy Software redundancy
Rack mounting	19-in. default 21- and 23-in. adapters available Note: Minimum 17.75-in. opening between posts is needed for proper operation
Cabinet mounting	Yes Note: Doors not recommended in enclosed cabinets
Wall mounting	No
Airflow	Right-to-back, Front-to-back with baffle
Performance
Fabric	One per RSP: ● Active/active nonblocking operation mode in dual-RSP redundant configuration ● Fully redundant in dual-RSP redundant configuration ● Built-in service-intelligence and traffic-prioritization capability
Thermal	Two fan trays: ● 6 high-efficiency fans per tray ● Variable-speed fans for optimal thermal performance ● No single point of failure
Power
Modularity	Pay-as-you-grow power for future scalability, available in AC and DC. Multiple power module types: ● 3 kW AC power module ● 2.1 kW DC power module Note: Mixing of AC and DC modules is not supported
Redundancy	● AC: N+N redundancy ● DC: N+1 redundancy ● Power module redundancy ● A/B Feed redundancy
Power zones	No power zone restrictions Fully load-sharing power infrastructure
Power input	Worldwide ranging AC (200-240V; 50-60 Hz; 16A maximum) Worldwide ranging DC (-40 to -72V; 50A nominal, 60A maximum)
Power-module airflow	Front-to-back
Operating temperature (nominal)	41 to 104ºF (5 to 40ºC)
Operating temperature (short-term)	ASR 9006: 23 to 131ºF (-5 to 55ºC) ASR 9010: 23 to 122ºF (-5 to 50ºC)
Operating humidity (nominal) (relative humidity)	5 to 90%
Storage temperature	-40 to 158ºF (-40 to 70ºC)
Storage (relative humidity)	5 to 93%
Operating altitude	-60 to 4000m (up to 2000m conforms to IEC/EN/UL/CSA 60950 requirements)
Network Equipment Building Standards (NEBS)	Cisco ASR 9006 is designed to meet: ● SR-3580: NEBS Criteria Levels (Level 3) ● GR-1089-CORE: NEBS EMC and Safety ● GR-63-CORE: NEBS Physical Protection ● VZ.TPR.9205: Verizon TEEER
ETSI standards	Cisco ASR 9006 is designed to meet: ● EN300 386: Telecommunications Network Equipment (EMC) ● ETSI 300 019 Storage Class 1.1 ● ETSI 300 019 Transportation Class 2.3 ● ETSI 300 019 Stationary Use Class 3.1
EMC standards emission	Cisco ASR 9006 is designed to meet: ● FCC Class 47CFR15 A ● ICES 003 Class A ● AS/NZS CISRP22 Class A ● CISPR 22 (EN55022) Class A ● VCCI Class A ● BSMI Class A ● IEC/EN 61000-3-12: Power Line Harmonics ● IEC/EN 61000-3-11: Voltage Fluctuations and Flicker ● EN55022: Information Technology Equipment (Emissions) ● EN 50121-4: Railway EMC
EMC standards immunity	Cisco ASR 9006 is designed to meet: ● IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air) ● IEC/EN-61000-4-3: Radiated Immunity (10V/m) ● IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal) ● IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM) ● IEC/EN-61000-4-5: Signal Surge Ports (1kV) ● IEC/EN-61000-4-5: Surge DC Port (1kV CM, 1kV DM) ● IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms) ● IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m) ● IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage Variations ● EN55024: Information Technology Equipment (Immunity) ● EN50082-1/EN-61000-6-1: Generic Immunity Standard ● EN 50121-4: Railway EMC
Safety	Cisco ASR 9006 is designed to meet: ● UL/CSA/IEC/EN 60950-1 ● IEC/EN 60825 Laser Safety ● ACA TS001 ● AS/NZS 60950 ● FDA Code of Federal Regulations Laser Safety

Q&A

What troubleshooting steps are common for the ASR-9006-DC-V2?

Check power supplies, network connectivity, and ensure the router has the latest firmware. Cisco support resources can assist with specific issues.

What accessories are recommended for the ASR-9006-DC-V2?

Recommended accessories include additional power supply modules, fan trays, and line cards to enhance the router's capabilities.

How does the ASR-9006-DC-V2 compare to other similar products?

The ASR-9006-DC-V2 offers superior scalability and performance compared to many other edge routers, making it a preferred choice for high-demand environments.

What category does the ASR-9006-DC-V2 fall under?

The ASR-9006-DC-V2 falls under Default Category/Routers/Cisco Routers/Cisco Router ASR 9000 and Default Category/Routers/Service Provider Edge Routers/Cisco ASR 9000 Router.

Learn More

How cost-effective is the Cisco ASR-9006-DC-V2 for system integrators?

The Cisco ASR-9006-DC-V2 offers high performance and scalability, balancing initial investment with long-term operational savings, making it cost-effective for system integrators.

What are the key characteristics of the Cisco ASR-9006-DC-V2?

The Cisco ASR-9006-DC-V2 features a robust chassis, high port density, modularity, and the latest PEM Version 2 for improved power efficiency.

What are the application scenarios for the Cisco ASR-9006-DC-V2?

The Cisco ASR-9006-DC-V2 is ideal for large-scale enterprise networks, service provider edge routing, and data center interconnects.

How do I install the Cisco ASR-9006-DC-V2 chassis?

The Cisco ASR-9006-DC-V2 installation involves mounting the chassis, connecting power modules, line cards, and configuring software according to the provided guide.

Does the Cisco ASR-9006-DC-V2 require software upgrades?

Yes, periodic software upgrades are recommended for the Cisco ASR-9006-DC-V2 to ensure optimal performance and security.

Are there alternative products to the Cisco ASR-9006-DC-V2?

Alternatives include other models in the Cisco ASR 9000 Series like ASR-9001, offering varying capacities based on needs.

What common troubleshooting steps are used for the Cisco ASR-9006-DC-V2?

Common steps include checking module connections, verifying power supply status, and consulting Cisco's diagnostic tools and logs.

What accessories are available for the Cisco ASR-9006-DC-V2?

Accessories include additional power entry modules (PEMs), fan trays, route processors, and line cards compatible with the ASR 9006 chassis.

How does the Cisco ASR-9006-DC-V2 compare with similar products?

The Cisco ASR-9006-DC-V2 offers higher scalability and performance compared to similar chassis with enhanced port density and power efficiency.

How reliable is the Cisco ASR-9006-DC-V2 for large networks?

The Cisco ASR-9006-DC-V2 is highly reliable, featuring redundant components and robust architecture, suitable for mission-critical large networks.
