7606S-RSP7C-10G-R - Cisco 7606 Router|LinkNewNet

7606S-RSP7C-10G-R - Cisco 7606 Router

Model: 7606S-RSP7C-10G-R

Detail: Cisco 7606S Chassis,6-slot,Red System,2RSP720-3C-10GE,2PS

Condition: Used

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Tags：

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

7606S-RSP7C-10G-R Specification
General
Device Type	Router - with 2 x Cisco 7600 Series Route Switch Processor 720 10GE with PFC-3C
Enclosure Type	Rack-mountable - modular - 7U
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Performance	IPv4 routing: 400 Mbps ¦ IPv6 routing: 200 Mbps ¦ Switching capacity: 720 Gbps
Capacity	IPv4 routes: 256000 ¦ IPv6 routes: 128000 ¦ NetFlow entries: 128000 ¦ ACL rules: 128000
Network / Transport Protocol	TCP/IP, ICMP/IP, DHCP
Routing Protocol	OSPF, RIP, BGP-4, IS-IS, IGMP, PIM-SM, PIM-DM, GRE, Bidirectional PIM
Features	Layer 3 switching, layer 2 switching, DHCP support, MPLS support, VLAN support, IGMP snooping, DoS attack prevention, Access Control List (ACL) support, Quality of Service (QoS), MPLS VPN, Virtual Route Forwarding-Lite (VRF-Lite)
Compliant Standards	IEEE 802.1x, NEBS level 3, ETSI, CISPR 22 Class A, EN 60950, EN 61000-3-2, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950, EN50082-1, AS/NZS 3260, AS/NZ 3548 Class A, CSA C22.2 No. 60950-00, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, FCC CFR21 Part 1040, IEC 60825-1, EN 60825-1
RAM	2 GB (installed) / 6 GB (max)
Flash Memory	1 GB (installed) / 2 GB (max)
Expansion / Connectivity
Interfaces	2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Management: 2 x console - RJ-45 ¦ 4 x SFP (mini-GBIC) ¦ 4 x X2
Expansion Slots	6 (total) / 4 (free) x expansion slot ¦ 6 (total) / 4 (free) x CompactFlash Card - type II
Installed Modules Qty (Max)	2 (installed) / 6 (max)
Power Device	Internal power supply - hot-plug
Power Redundancy	Yes
Installed Qty	2 (installed) / 2 (max)
Rack Mounting Kit	Included
MTBF	400,000 hours

Q&A

What common issues might arise with the Cisco 7606S Chassis?

Common issues include power supply failures, RSP module errors, and cooling fan malfunctions. Regular maintenance and monitoring can mitigate these problems.

What accessories come with the Cisco 7606S Chassis?

The chassis comes with redundant RSP720-3C-10GE modules and two power supplies. Additional accessories, such as line cards and interface modules, need to be purchased separately.

How does the Cisco 7606S Chassis compare to the Cisco ASR 1000 Series?

The Cisco 7606S Chassis offers extensive Ethernet support and legacy compatibility, while the ASR 1000 Series provides higher throughput and advanced service features for modern networks.

What is the warranty for a used Cisco 7606S Chassis?

The warranty for used Cisco 7606S Chassis varies by vendor, but it typically includes a limited warranty period. Always check with your supplier for detailed warranty terms.

What are the main features of the Cisco 7606S Chassis?

The Cisco 7606S Chassis is a 6-slot router with redundant RSP720-3C-10GE and power supplies, designed for high-performance and reliability in WAN aggregation and internet edge applications.

Is the Cisco 7606S Chassis cost-effective for system integrators?

Yes, the used Cisco 7606S Chassis offers significant cost savings while providing robust performance suitable for medium to large enterprise networks.

What application scenarios are suitable for the Cisco 7606S Chassis?

The Cisco 7606S Chassis is ideal for WAN aggregation, internet edge routing, and high-density Ethernet and gigabit deployments.

How do I install the Cisco 7606S Chassis?

Installation involves mounting the chassis in a rack, connecting the power supplies, and configuring the RSP720-3C-10GE modules according to your network requirements.

Does the Cisco 7606S Chassis need a software upgrade?

It depends on your network needs; upgrading the IOS software can provide new features and security patches. Ensure compatibility with your specific hardware configuration.

Are there alternative products to the Cisco 7606S Chassis?

Alternatives include the Cisco ASR 1000 Series and the Cisco 6500 Series, each with different performance and feature sets tailored to specific network requirements.
