7603S-RSP720C-P - Cisco 7603 Router

Model: 7603S-RSP720C-P

Detail: Cisco 7603S Chassis,3-slot,RSP720-3C,PS

Condition: Used

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Tags：

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

7603S-RSP720C-P Specification
General
Device Type	Router - with Cisco 7600 Series Route Switch Processor 720 with PFC-3C
Enclosure Type	Rack-mountable - modular - 4U
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Performance	IPv4 routing: 400 Mbps ¦ IPv6 routing: 200 Mbps ¦ Switching capacity: 720 Gbps
Capacity	IPv4 routes: 256000 ¦ IPv6 routes: 128000 ¦ NetFlow entries: 128000 ¦ ACL rules: 128000
Network / Transport Protocol	TCP/IP, ICMP/IP
Routing Protocol	OSPF, RIP, BGP-4, IS-IS, IGMP, PIM-SM, PIM-DM
Features	Layer 3 switching, layer 2 switching, dynamic IP address assignment, DHCP support, MPLS support, VLAN support, IGMP snooping, traffic shaping, DoS attack prevention, Access Control List (ACL) support, Quality of Service (QoS)
Compliant Standards	IEEE 802.1x, NEBS level 3, FCC Class A certified, CISPR 22 Class A, EN 60950, EN 61000-3-2, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950, EN50082-1, AS/NZ 3548 Class A, CSA C22.2 No. 60950-00, ICES-003 Class A, EN300-386
Processor	PowerPC 1.2 GHz
RAM	2 GB (installed) / 6 GB (max)
Expansion / Connectivity
Interfaces	1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Management: 1 x console - RJ-45 ¦ 2 x SFP (mini-GBIC)
Expansion Slots	3 (total) / 2 (free) x expansion slot ¦ 3 (total) / 2 (free) x CompactFlash Card - type II
Installed Modules Qty (Max)	1 (installed) / 3 (max)
Power Device	Internal power supply - hot-plug
Power Redundancy	Yes
Installed Qty	1 (installed) / 2 (max)
Rack Mounting Kit	Included
Width	17.4 in
Depth	20.3 in
Height	7 in
Weight	27.12 lbs

Q&A

What are common troubleshooting steps for the Cisco 7603S-RSP720C-P?

Common steps include checking power connections, verifying software versions, and consulting Cisco support for hardware diagnostics.

What accessories are available for the Cisco 7603S-RSP720C-P?

Available accessories include additional power supplies, line cards, and interface modules to extend functionality.

How does the Cisco 7603S-RSP720C-P compare to the Cisco ASR 1000 series?

The Cisco 7603S-RSP720C-P is less expensive but offers lower performance and fewer features compared to the Cisco ASR 1000 series.

What category does the Cisco 7603S-RSP720C-P fall under?

It belongs to the Default Category/Routers/Cisco Routers/Cisco Router 7600 Series and Default Category/Routers/WAN Aggregation and Internet Edge Routers/Cisco 7600 Routers.

How cost-effective is the Cisco 7603S-RSP720C-P?

The Cisco 7603S-RSP720C-P offers robust performance at a fraction of the cost of new units, making it an economical choice for system integrators.

What are the key features of the Cisco 7603S-RSP720C-P?

Key features include a 3-slot chassis, RSP720-3C processor, and high performance suitable for WAN aggregation.

What are the typical application scenarios for the Cisco 7603S-RSP720C-P?

Ideal for medium to large enterprises requiring WAN aggregation and high-speed internet edge routing.

How do I install the Cisco 7603S-RSP720C-P?

Follow the installation manual provided by Cisco, ensuring proper physical installation in a suitable rack and correct connection of power supply.

Does the Cisco 7603S-RSP720C-P require software upgrades?

Although used, it's advisable to check for the latest software updates on Cisco's website to ensure optimal performance.

Are there alternative products to the Cisco 7603S-RSP720C-P?

Alternatives include newer models from the Cisco ASR 1000 series, which provide advanced features and higher performance.
