WS-X6716-10G-3CXL - Cisco Catalyst 6500 Ethernet Module

Model: WS-X6716-10G-3CXL

Detail: Catalyst 6500 16 port 10 Gigabit Ethernet w/ DFC3CXL(req X2)

Condition: USED

Shipping: DHL, FedEx, UPS, etc

Availability: In Stock

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

WS-X6716-10G-3CXL Specifications
Physical specifications	● Occupies one slot in the Cisco Catalyst 6500 Series chassis or Cisco 7600 Series chassis ● Dimensions (H x W x D): 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm) ● Weight: ◦ Cisco Catalyst 6708 and 6716: 13 pounds excluding X2 components; ¼ pound for each X2 ◦ Cisco Catalyst 6704: 10 pounds excluding XENPAK and DFC components; 2/3 pound for each XENPAK
Regulatory compliance	Cisco Catalyst 6500 Series 10 Gigabit Ethernet modules, when installed in a system, comply with the following EMC and safety standards: EMC Standards: ● FCC Part 15 (CFR 47) Class A ● ICES-003 Class A ● VCCI Class A ● EN55022 Class A ● EN55024 ● CISPR24 ● CISPR 22 Class A ● AS/NZS CISPR 22 Class A ● ETS 300 386 ● KN 22 Class A ● EN 50082-1 ● EN61000-3-2 ● EN61000-3-3 ● EN61000-6-1 ● CNS13438 Class A ● KN6100 -4 Series Safety Standards: ● UL 60950-1 ● CAN/CSA C22.2 No. 60950 ● EN 60950-1 ● IEC 60950-1 ● AS/NZS 60950-1 ● IEC 60825 Class 1 ● EN 60825 Class 1 ● 21CFR 1040
NEBS criteria levels	SR-3580 Issue 3, June 2007 (GR-63-CORE, issue 3, and GR-1089-CORE, issue 4)
ETSI	● ETS 300 019-2-1, Class 1.1 Storage ● ETS 300 019-2-2, Class 2.1 and 2.2 Transportation ● ETS 300 019-2-3, Class 3.1E Stationary Use
Network management	● ETHERLIKE-MIB (RFC 1643) ● IF-MIB (RFC 1573) ● Bridge MIB (RFC 1493) ● CISCO-STACK-MIB ● CISCO-VTP-MIB ● CISCO-CDP-MIB ● RMON MIB (RFC 1757) ● CISCO-PAGP-MIB ● CISCO-STP-EXTENSIONS-MIB ● CISCO-VLAN-BRIDGE-MIB ● CISCO-VLAN-MEMBERSHIP-MIB ● ENTITY-MIB (RFC 2037) ● HC-RMON ● RFC1213-MIB (MIB-II) ● SMON-MIB
Power requirements	● WS-X6716-10T-3C: 509.3W (12.1A @ 42V) ● WS-X6716-10T-3CXL: 538.7W (12.8A @ 42V) ● WS-X6716-10G-3C: 457.8W (10.9A @ 42V) ● WS-X6716-10G-3CXL: 487.2W (11.6A @ 42V) ● WS-X6708-10G-3C: 444.36W (10.58A @ 42v) ● WS-X6708-10G-3CXL: 473.76w (11.28A @ 42V) ● WS-X6704-10GE with DFC3CXL: 362.46W (8.63A @ 42V) ● WS-X6704-10GE with DFC3C: 333.06W (7.93A @ 42V) ● WS-X6704-10GE with DFC3BXL: 402.36W (9.58A @ 42V) ● WS-X6704-10GE with DFC3B: 377.16W (8.98A @ 42V) ● WS-X6704-10GE with DFC3A: 389.76W (9.28A @ 42V) ● WS-X6704-10GE with CFC: 295.26W (7.03A @ 42V)
Indicators	● Status: green (operational), red (faulty), and orange (module booting) ● Link: green (port enabled and connected), orange (port disabled), and off (port enabled and not connected)
