Huawei CloudEngine 5800 Series Switch CE5855-48T4S2Q-EI

Model: CE5855-48T4S2Q-EI

Detail: Huawei CE5855-48T4S2Q-EI Switch(48-Port GE RJ45,4-Port 10G SFP+,2-Port 40G QSFP+

Condition: Used

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

CE5855-48T4S2Q-EI
Product list
Product code	CE5855-48T4S2Q-EI
Power cable	No
Button	No
Product parameters
Network Ports	48
RJ-45 Ports	48
Ethernet Technology	Gigabit Ethernet
Network Technology	10/100/1000Base-T
Layer supported	2
Introduction	Huawei CloudEngine 5800 series (CE5800) switches are next-generation, high-density Gigabit Ethernet switches designed for data centers and high-end campus networks. The CE5800 hardware has an advanced architectural design with the industry's highest density of GE access ports. The CE5800 is also the first Gigabit Ethernet access switch to provide 40GE uplink ports. Using the Huawei VRP8 software platform, CE5800 switches support Transparent Interconnection of Lots of Links (TRILL) and have a high stacking capability (up to 16-member switches in a stack system).
Maximum power consumption	103 W
Typical power consumption	76 W
Typical heat dissipation	259 BTU/hr
Maximum heat dissipation	351 BTU/hr
Switching capacity	336 Gbit/s
Forwarding rate	252 Mpps
Buffer	8 MB
Power Device
Power Source	Power Supply
Input Voltage	110 V AC 220 V AC
Physical specifications
Width	442 mm
Height	43.6 mm
Depth	420 mm
Weight	18.5 lbs
Environmental Parameters
Min Temperature	23 °F
Max Temperature	113 °F
Humidity Operating	10 - 90% (non-condensing)

Q&A

Q Why can't I access the WLAN view on the switch?

A As-mode disable needs to be used to enable WLAN feature.

Q Why are Switch Ports down and faulty due to power over current?

A No faults with the switch, so we need to check the IP Phones. Power overcurrent: indicates that the current of the PD connected to the interface exceeds the maximum current of the interface.

Q What Are the Common Causes for SSH Login Failure on S Series Switches?

A The configuration is incorrect. For example, the STelnet service is disabled on the switch. Solution: Check whether the configuration is correct and complete by referring to "Example for Configuring STelnet Login."

Q What is the difference between Cisco and Huawei?

A Huawei uses only open standard protocols whereas Cisco uses a mixture of open and proprietary.
