CVR-CFP2-CPAK4= - Cisco QSFP28 Module|LinkNewNet

CVR-CFP2-CPAK4= - Cisco QSFP28 Module

Model: CVR-CFP2-CPAK4=

Detail: CFP2 to CPAK adapter for 4x25G interface

Condition: Used

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Tags：

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

CVR-CFP2-CPAK4= Specification
Description			Cisco QSA Module
Dimensions			17.3mm x 41.6mm x 153mm
Optical Transmit and Receive Specifications
Adapter - CPAK Combination		CVR-CFP2-CPAK4 w/ CPAK-LR4			CVR-CFP2-CPAK4 w/ CPAK-ER4L
Λ(nm)		1295.56 1300.05 1304.58 1309.14			1295.56 1300.05 1304.58 1309.14
Architecture		4x25			4x25
Protocol		IEEE 802.3ae			IEEE 802.3ae
Lane		25.78125			25.78125
Optical		100GBASE-LR4			100GBASE-ER4L
Max BER		10-12			10-12
Cable Type		SMF G.652			SMF G.652
Link		10km			<40km
Optics Connector		SC duplex			SC duplex
Adapter with CPAK Module Power Supply Requirements
Voltage Supply (V)			3.3
Symbol			Vcc
DC Tolerance (%)			+/-5
Peak Inrush Current (mA)			4306
Max. Current (mA)			2871
Max. Current Ramp rate mA/µs			100
Maximum Power (W)		Low-power mode is negated			LR4: 9 SR10, 10x10G-LR: 5.5
		Low-power mode is asserted			LR4: 5 SR10, 10x10G-LR:
Adapter Operating Conditions
	PID	Min	Typ.	Max	Unit
Case Temperature	CVR-CFP2-CPAK4/ CVR-CFP2-CPAK10	0	\	70	°C
Power supply voltage	CVR-CFP2-CPAK4/ CVR-CFP2-CPAK10	3.135	3.3	3.465	V
Power consumption (EOL)	CVR-CFP2-CPAK4/ CVR-CFP2-CPAK10 without CPAK	\	\	1	W
	CVR-CFP2-CPAK4w/ CPAK-LR4	\	\	9
Environmental conditions and power requirements
Storage temperature range			-40° to 85°C (-40°to 185°F)
Operating temperature range			0° to 70°C (32° to 158°F)

Q&A

What troubleshooting steps are common for the CVR-CFP2-CPAK4=

Ensure proper seating of the adapter and connections, and verify compatibility with existing network hardware.

What accessories are available for the CVR-CFP2-CPAK4=?

You may need standard CFP2 and CPAK modules, as well as appropriate 25G transceivers.

How does the CVR-CFP2-CPAK4= compare to similar products?

The CVR-CFP2-CPAK4= offers a seamless interface transition with minimal latency, making it superior to some competing adapters.

What are the benefits of using the CVR-CFP2-CPAK4=?

It enables a smooth upgrade path from CFP2 to CPAK, enhancing network performance and extending equipment life.

How cost-effective is the CVR-CFP2-CPAK4=?

The CVR-CFP2-CPAK4= provides a cost-efficient solution for upgrading existing CFP2 interfaces to CPAK for enhanced performance.

What are the key features of the CVR-CFP2-CPAK4=?

The CVR-CFP2-CPAK4= features compatibility with 4x25G interfaces, facilitating seamless integration and high-speed data transfer.

What are the application scenarios for the CVR-CFP2-CPAK4=?

This adapter is ideal for data centers and enterprise networks requiring upgraded 100G optical connections.

How do I install the CVR-CFP2-CPAK4=?

Simply insert the adapter into a compatible CFP2 slot, then connect the CPAK module into the adapter.

Does the CVR-CFP2-CPAK4= require firmware upgrades?

No, the CVR-CFP2-CPAK4= typically does not require firmware upgrades. Check compatibility requirements.

Are there alternative products to the CVR-CFP2-CPAK4=?

Alternative products might include other Cisco 100G optical modules or third-party adapters with similar functionality.

What troubleshooting steps are common for the CVR-CFP2-CPAK4=

Ensure proper seating of the adapter and connections, and verify compatibility with existing network hardware.

What accessories are available for the CVR-CFP2-CPAK4=?

You may need standard CFP2 and CPAK modules, as well as appropriate 25G transceivers.

How does the CVR-CFP2-CPAK4= compare to similar products?

The CVR-CFP2-CPAK4= offers a seamless interface transition with minimal latency, making it superior to some competing adapters.

What are the benefits of using the CVR-CFP2-CPAK4=?

It enables a smooth upgrade path from CFP2 to CPAK, enhancing network performance and extending equipment life.
