S5720S-52P-SI-AC Specification | |
Fixed Port | 48 × 10/100/1000BASE-T ports 4 × Gig SFP ports |
Dimensions (W x D x H) | 44.2 cm x 22 cm x 4.36 cm |
IP routing | Static routing |
RIPv1, RIPv2 and RIPng,ECMP(supported by the S5700-SI/S5700-EI/S5700-HI series) | |
OSPF, OSPFv3, IS-IS, IS-ISv6, BGP and BGP4+ (supported by the S5700-EI/S5700-HI series) | |
Access Security | DHCP Relay, DHCP Server, DHCP Snooping, DHCP Security |
Interoperability | Supports VBST (Compatible with PVST/PVST+/RPVST) |
Supports LNP (Similar to DTP) | |
Supports VCMP (Similar to VTP) | |
Operating environment | Operating temperature: 0℃–50℃ |
Relative humidity: 10%–90% (non-condensing) | |
Input voltage | AC: Rated voltage range: 100 V to 240 V AC, 50/60 Hz Maximum voltage range: 90 V to 264 V AC, 47/63 Hz |
