NM-16A - Cisco Interface Card Network Modules|LinkNewNet

HWIC-1T - Cisco High-Speed WAN Interface Cards

Model: HWIC-1T

Detail: 1-Port Serial WAN Interface Card

Condition: USED

Shipping: DHL, FedEx, UPS, etc

Availability: In Stock

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Tags：

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

HWIC-1T Specifications
Manufacturer	Cisco
Part Number	HWIC-1T
Device Type	Expansion module
Form factor	Plug-in module
Specifications
Synchronous Support	Yes
Synchronous Maximum Speed (Per Port)	8 Mbps
Asynchronous Support	Yes
Asynchronous Maximum Speed (Per Port)	115.2 kbps
Bisync Support	Yes
Serial Protocols	EIA-232, EIA-449, EIA-530, EIA-530A, V.35, and X.21
Network Clock Synchronization	Yes
NEBS	Type 2/4
TelecommPTT	TBR1 and 2 JATE Digital NEBS
Safety Approvals	UL 60950, CAN/CSA 22.2, CSA60950, GB 4943, AS/NZS 60950, EN60950, IEC 60950
Immunity	EN300386, CISPR24, EN55024, EN50082-1, 61000-4-2/3/4/5/6/8/11
Emissions	FCC Part 15 Class A, ICES-003 Class A, EN55022 Class A, CISPR22 Class A, AS/NZSCISPR22 Class A, VCCI Class A, EN 300386, EN61000-3-2/3, CNS13438
Physical Specifications	Singlewide HWIC, no slot restrictions Dimensions (H x W x D) 0.8 x 3.1 x 5.6 in. (2.1 x 7.9 x 14.2 cm)
Environmental Specifications	Operating temperature: 32 to 104°F (0 to 40°C) NEBS short-term operating temperature: 32 to 131°F (0 to 50°C) Storage temperature: -4 to 149°F (-20 to 65°C) Relative humidity: 10 to 90%, noncondensing

Q&A

What accessories are required for the HWIC-1T?

The HWIC-1T typically requires compatible cables for connecting to the WAN, which are sold separately. Ensure to check the specifications for suitable cable types.

How does the HWIC-1T compare to similar products?

The HWIC-1T is a highly reliable, cost-effective option compared to similar products, offering robust performance and flexibility for various WAN connections.

What are common troubleshooting steps for the HWIC-1T?

Common troubleshooting includes checking physical connections, verifying interface configurations, and ensuring that the card is properly seated in the HWIC slot.

What are the product features of the HWIC-1T?

The HWIC-1T includes high-speed serial WAN connectivity with support for multiple protocols, which ensures adaptable and reliable WAN connections for Cisco routers.

How cost-effective is the HWIC-1T for system integrators?

The HWIC-1T offers superior cost-effectiveness by providing high-speed serial WAN connectivity at an affordable price point, making it a budget-friendly choice for system integrators.

What are the key characteristics of the HWIC-1T?

The HWIC-1T features a single-port high-speed serial WAN interface, supporting various protocols like HDLC and PPP, ensuring flexible connectivity options.

What application scenarios is the HWIC-1T suitable for?

The HWIC-1T is ideal for applications requiring reliable high-speed WAN connectivity, such as remote office networking, branch connections, and enterprise WAN deployments.

How do I install the HWIC-1T on a Cisco router?

To install the HWIC-1T, simply insert the card into an available HWIC slot on your Cisco router and secure it properly, ensuring to follow the router's installation guidelines.

Does the HWIC-1T need firmware upgrades?

Regular firmware updates are recommended for the HWIC-1T to ensure optimal performance and compatibility with the latest Cisco IOS features.

Are there alternative products to the HWIC-1T?

Yes, Cisco offers various other WAN interface cards such as the HWIC-2T and WIC-2A/S, which offer different port counts and features to meet diverse networking needs.
